Code: CAR-CR11L
VEHICLE CAMERA CAR-CR11L STANDARD: PAL,
Net: 15.26 GBP Gross: 18.77 GBP
Rear view vehicle camera designed for Chrysler Cruiser. Shockproof
camera housing. Very useful at poor rear view visibility on your car.
It is mounted in place of car plate light. Camera is additionally
equipped with independent powered LED, which illuminates the car
plate.
In case of factory-mounted monitors, you should check if they are
compatible with PAL signal standard.
SPECIFICATION
Standard:
PAL
Sensor:
1/3 " CMOS
Resolution:
420 TVL
View angle:
120 °
Min. illumination:
1.0 Lux
Video output:
1.0 Vpp / 75 Ω
Displayed image:
Mirror function - the image is displayed as rear mirror view with scale which helps
evaluate the distance
Power supply:
12 V DC / 60 mA
Operation temp:
-20 °C ... 75 °C
"Index of Protection":
IP67
Length of the camera power cable:
1.8 m
Length of the included video cable:
6m
Dimensions:
68 x 51 x 70 mm
Guarantee:
2 years
PRESENTATION
DELTA-OPTI Monika Matysiak / VAT:PL5251295225 / 60-713 Poznań, ul. Graniczna 10
Tel:+48 61 866 71 48 / GSM:+48 607 60 11 66 / Fax:+48 61 864 69 65 / e-mail:[email protected]
Monday-Friday: 8.00-19.00 / Saturday: 8.00-14.00
2017-03-08
CAR-CR11L
1/4
Camera dimensions:
DELTA-OPTI Monika Matysiak / VAT:PL5251295225 / 60-713 Poznań, ul. Graniczna 10
Tel:+48 61 866 71 48 / GSM:+48 607 60 11 66 / Fax:+48 61 864 69 65 / e-mail:[email protected]
Monday-Friday: 8.00-19.00 / Saturday: 8.00-14.00
2017-03-08
CAR-CR11L
2/4
Rear view:
In the kit:
OUR TESTS
DELTA-OPTI Monika Matysiak / VAT:PL5251295225 / 60-713 Poznań, ul. Graniczna 10
Tel:+48 61 866 71 48 / GSM:+48 607 60 11 66 / Fax:+48 61 864 69 65 / e-mail:[email protected]
Monday-Friday: 8.00-19.00 / Saturday: 8.00-14.00
2017-03-08
CAR-CR11L
3/4
Camera image screenshot (Mirror function).
The image is displayed as rear mirror view with scale which helps evaluate the distance:
OUR OPINIONS
Attention! The device is not intended to continuous work 24/7.
PACKAGE PARAMETERS
Dimensions (L x W x H): 135x75x55 mm Package: Karton Gross Weight: 0.21 kg
