MB ACTROS 4444 8x4 EURO4 CONCRETE PUMP CIFA

MB ACTROS 4444 8x4 EURO4 CONCRETE PUMP CIFA

Truckport Sp. z o.o.
ul. Kamienna 2
49-120 Dąbrowa k/ Opola
tel.: +48 77 400 38 40
fax: +48 77 400 38 41
MB ACTROS 4444 8x4 EURO4 CONCRETE PUMP CIFA K52L-XRZ
Brand:
MB ACTROS 4444 8x4
EURO4 CONCRETE
PUMP CIFA K52L-XRZ
Type:
Concrete pumps
First registration: 05/2008
AXLES, TIRES, BRAKES
5900 mm / 7260 mm
Suspension type front
spring
Suspension type rear
spring
Breakes front
drum brakes
Breakes rear
drum brakes
Axle 1
385/65 R22.5 - 9000 kg
Axle 2
385/65 R22.5 - 9000 kg
Axle 3
385/65 R22.5 - 13000 kg
Axle 4
385/65 R22.5 - 13000 kg
APPEARANCE & OPTIONS
ABS
Electric windows
Electric mirrors
Heated mirrors
Radio
Central locking system
AC
Differential lock
160475 km
Engine power:
440 KM
EURO norm:
EURO 4
Gearbox:
manual
Axles:
8x4
Color:
white
Nr VIN:
WDB9323171L249686
Nr ref.:
T100008
MASS & CAPACITY
Wheelbase
Cabin
Mileage:
Length/width/height
Empty weight
11660 mm / 2500 mm / 4000
mm
40300 kg
GVW
44000 kg
ADDITIONAL DESCRIPTION
daily
VIN: L249686
Placing boom CIFA B5RZ 52/48:
-pipeline diameter 125 mm
-max. vertical reach 51100 mm
-max. horizontal distance 46800 mm
-section numbers 6
-1st section opening angle 90°
-2nd section opening angle 180°
-3rd section opening angle 180°
-4rd section opening angle 254°
-5rd section opening angle 210°
-6rd section opening angle 90°
-rotating angle 370°
Pumping unit CIFA HPG 1808/1113 IF9:
-max. theoretical output 179/105 m3/h
-max. pressure on concrete 76/130 bar
-max. number of cycles per minute 36/21
-concrete cylinders (diam. x stroke) 230x2000 mm
-concrete hopper capacity 650L
-Hydraulic circuit closed
Working hours: 2432 hours
2 radio remote controls
