Tetrahedron 58 (2002) 2621±2625
Experimental demonstration of anomeric effect and structure:
X-ray conformational and con®gurational analysis of
N-2-(1,4-dioxane)-N 0-(p-methylbenzenesulfonyl)-O(p-methylphenoxy) isourea
Hossein A. Dabbagh,a,p Ali Reza Modarresi-Alam,a,² Azadeh Tadjarodib and Abbas Taebb
b
a
College of Chemistry, Isfahan University of Technology, Isfahan 84156, Iran
X-Ray Research Laboratory, University of Science and Technology, Tehran, Iran
Received 15 November 2001; revised 2 January 2002; accepted 31 January 2002
AbstractÐThe conformational, con®gurational behavior and the structure of N-2-(1,4-dioxane)-N 0 -(p-methylbenzenesulfonyl)-O(p-methylphenoxy) isourea (1) has been studied using X-ray crystallographic analysis. The endo-anomeric effect controls the population
of dioxane ring conformers or anomers but not the con®guration interconversion of the imine of the imidoyl moiety. X-Ray analysis of 1
demonstrates that the dioxane ring adopts the chair conformation, that the imidoyl amino group prefers axial conformation and that the
tosyl and tolyl groups about the CvN bond retain the E con®guration. Isourea (1) was synthesized by the thermal decomposition of
N 0 -(p-methylbenzenesulfonyl)-O-(p-methylphenoxy) imidoyl azide in re¯uxing dioxane. q 2002 Elsevier Science Ltd. All rights reserved.
1. Introduction
In recent years, an increasing number of investigations have
been concerned with the anomeric effect and the conformational analysis of tetrahydropyrans, 1,3-dioxanes, glycosides and other cyclohexane derivatives.1±29 Salzner
revisited the origin of the anomeric effect and concluded
that anomeric effects are due to charge back donation
from lone pairs rather than dipole repulsions.30 There have
been comparatively fewer reports on 1,4-dioxane and its
substituted analogs.25±29,34 The major area of interest has
been pharmaceutical activities of 1,4-dioxanes.25±29 The
anomeric effect is well recognized as an important factor
in de®ning the predominant conformational state of many
cyclic heteroatom-containing compounds. The geometry of
the conformations of the transition state and/or of the
intermediate is documented to pre-establish the selectivity
of the chemical reactions and/or the stereochemistry of the
adducts.31±33 Since it is entirely conceivable that the
pharmaceutical activity is related to the physicochemical
properties of the dioxanes, a thorough investigation of
1,4-dioxane derivatives was initiated many years
ago.17,18,22,25±29,34 Recently, dynamic conformational
analysis and X-ray crystallography of 9,10-bisbromomethyl-1,4,5,8-tetraoxadecalin
(4a,8a-bisbromomethylKeywords: anomeric effect; conformational analysis; con®gurational
analysis.
p
Corresponding author; e-mail: [email protected]
²
Present address: Department of Chemistry, Sistan and Baluchestan
University, Zahedan, Iran.
hexahydro-p-dioxino)[2,3-b]-p-dioxane was undertaken by
Fuchs and co-workers.34a They proved that this tetraoxadecaline has cis con®guration and adopts double chair
conformation.
The purpose of the present paper is to provide evidence,
which will serve to establish that the large imidoylamino
group [(p-CH3 ±C6H4 ±O±CvN±SO2 ±C6H4 ±CH3-p)±NH±
] adopts an axial position (the anomeric effect). Additional
aims of this report are to investigate the factors that contribute to this axial preference and to study the conformations
and con®gurations of 1, Scheme 1.
Scheme 1.
We believe, this system allows us to shed more light on the
phenomenon known as the anomeric effect.
We synthesized N-2-(1,4-dioxane)-N 0 -(p-methylbenzenesulfonyl)-O-(p-methylphenoxy) isourea (1) and characterized it by 1H, 13C NMR, mass spectral analysis, IR and
elemental analysis. Second, we studied the structure,
0040±4020/02/$ - see front matter q 2002 Elsevier Science Ltd. All rights reserved.
PII: S 0040- 402 0( 02) 00130- 8
2622
H. A. Dabbagh et al. / Tetrahedron 58 (2002) 2621±2625
methylphenoxy) isourea (1) was synthesized by the thermal
decomposition of N 0 -(p-methylbenzenesulfonyl)-O-(pmethylphenoxy) imidoyl azide (2) in re¯uxing dioxane,
Scheme 1.
2.2. X-Ray crystallographic analysis
Figure 1. Molecular structure of 1 from X-ray crystallographic analysis.
Scheme 2.
conformation of 1,4-dioxane, con®guration of the imine
group of the imidoyl moiety and the anomeric effect using
X-ray crystallographic analysis.
2. Results and discussion
2.1. Synthesis
N-2-(1,4-Dioxane)-N 0 -(p-methylbenzenesulfonyl)-O-(p-
The molecular structure of 1 was analyzed by X-ray
crystallography, Fig. 1 and Scheme 2. Selected bond
angle, bond length and torsion angle are summarized in
Tables 1±3. The following observations are made based
on the X-ray analysis of 1. (a) The dioxane ring retains the
chair conformation. (b) The imidoyl amino group (HN±G,
Gˆp-Me±C6H4 ±O±CvN±SO2 ±C6H4 ±Me-p) prefer the
axial position. (c) The tosyl and tolyl groups about the
CvN bond (N1±C3) are in trans position (i.e. E isomer).
(d) The SvO3 and the Tol±O (O1±C14) bonds holds the
s-cis conformation with the CvN bond (the torsion angle is
almost equal to zero). (e) There is a relatively strong intramolecular hydrogen bond between the N±H and the oxygen
of SvO3, Fig. 1, Scheme 2, Tables 1±3. The SvO3 bond
Ê ) is longer than SvO2 (1.34 A
Ê ). The S±N1
length (1.433 A
Ê ) is shorter than a normal S±N bond
bond length (1.607 A
Ê ) is
Ê ).35,36 The N2±C3 bond length (1.331 A
(1.634 A
2
2 35
approximately equal to N(sp )±C(sp ). The C3±N2±C31
bond angle is equal to 1208 which indicates sp2 hybridization for the nitrogen atom. The s-cis conformation of
SvO3, N1±C3 bonds and the SvO3´ ´ ´H±N hydrogen
bond helps the formation of a stable six-membered ring.
Ê ) indicates the sp2
The C14±O1±C3 bond angle (117.7 A
Ê)
hybridization for O1. The C3±O1 bond length (1.340 A
Ê ) and typiis somewhat shorter than C14±O1 bond (1.420 A
Ê ).35 This indicates the C3±O1
cal ArO±CO-bonds (1.360 A
bond has double bond character.
The endo-anomeric effect29 in 1 is demonstrated by the
following observations. The O4±C31 bond length
Ê ) is shorter than O4±C34 (1.480 A
Ê ) and O±C of
(1.420 A
Ê ) bonds. The N2±C31 bond length
tetrahydropyran (1.441 A
Ê ) and typiÊ ) is longer than C(sp3)±N(sp2) (1.454 A
(1.460 A
37±39
Ê
The C34±O4±C31
cal ±N±C±O± (1.440 A) bonds.
bond angle (1158) is longer than C33±O5±C32 (111.98).
The torsion angle (a) O4±C31±C32±O5 (54.348) is smaller
than (b) O4±C34±C33±O5 (57.048). The torsion angle in
the 1,4-dioxane ring is 578.40,41
The repulsion between the hydrogen of the H±N±G group
and the axial hydrogen at C34 (1,3-repulsion) distorts the
Table 1. Selected bond angle (degrees) calculated by X-ray crystallographic analysis
Atom 1
Atom 2
Atom 3
Bond angle
Atom 1
Atom 2
Atom 3
Bond angle
C24
C24
C24
N1
N1
O3
C3
S
S
C14
O1
S
S
S
S
S
S
N2
N24
N1
O1
C14
N1
O3
O2
O3
O2
O2
C31
C23
C3
C3
C15
101.9 (3)
108.8 (4)
108.5 (4)
113.6 (3)
107.0 (4)
116.0 (4)
123.0 (6)
118.7 (6)
124.5 (5)
117.7 (6)
118.0 (7)
N2
N2
N1
C32
O5
C31
O5
N2
N2
C32
O4
C3
C3
C3
O5
C32
O4
C33
C31
C31
C31
C34
N1
O1
O1
C33
C31
C34
C34
C32
O4
O4
C33
127.4 (7)
114.2 (6)
118.2 (6)
111.9 (6)
108.4 (6)
115. 0 (6)
108.7 (7)
108.2 (6)
109.5 (6)
110.9 (7)
107.6 (7)
