Injection laryngoplasty with autologous
fat in patients after laser cordectomy
(preliminary report)
Laryngoplastyka iniekcyjna z wykorzystaniem autogennego
tłuszczu u pacjentów po chordektomii laserowej (doniesienie
wstępne)
Bruzgielewicz Antoni, Sielska-Badurek, Ewelina, Niemczyk Kazimierz, Osuch-Wójcikiewicz Ewa
Department and Chair of Otolaryngology at the Medical University of Warsaw, Warsaw, Poland, Clinic head: Prof. Kazimierz Niemczyk MD, PhD
Article history: Received: 15.05.2015 Accepted: 21.05.2015 Published: 30.06.2015
ABSTRACT:Transoral endoscopic laser surgery has been widely used in the treatment of the early stage of glottic cancer. Phonato-
ry dysfunction is the main problem after cordectomy. The quality of voice depends on the extent of surgery, especially
when resection involves the anterior commissure, vocal process, arytenoid or contralateral vocal folds. Many of surgery
(phonosurgery) procedure is performed to improve the activity of the larynx phonatory function.
One of them is the autologous fat injection. The aime of this study is evaluation of possibilities of injecting laryngoplasty with autogenous fat in patients after laser cordectomy to improve phonatory function of the larynx (preliminary
report).
Two patients, underwent CO2 laser cordectomy type III because of T1aN0M0 glottic carcinoma.
After surgery, respectively in the 7th and 8th month, patients were injected on autologous fat into the rest of the vocal
fold. Before and after laryngoplasty phoniatric and subjective and objective evaluation of the voice were performed.
As a result of the injecting laryngoplasty we observed improvement of the glottic closure, phonatory quality voice and
voice perceptual improvement. Injecting laryngoplasty with autologous fat in patients after laser cordectomy is highly
recommended, especially after type III laser cordectomy.
KEY WORDS:
vocal fold carcinoma, cordectomy, autologous fat augmentation
STRESZCZENIE: rzezustna endoskopowa chirurgia laserowa znalazła różnorodne zastosowanie w leczeniu wybranych przypadków raka
P
głośni we wczesnym stopniu zaawansowania klinicznego. Po chordektomii dochodzi do zaburzeń czynności fonacyjnej,
a jakość głosu w dużej mierze zależy od rozległości zabiegu operacyjnego, szczególnie gdy resekcją jest objęte spoidło
przednie, wyrostek głosowy, nalewka czy drugi fałd głosowy. Aby poprawić czynność fonacyjną krtani, wykonuje się wiele
zabiegów chirurgicznych (fonochirurgicznych). Jednym z nich jest iniekcja autogennego tłuszczu. Celem niniejszej pracy
jest ocena możliwości laryngoplastyki iniekcyjnej z wykorzystaniem autogennego tłuszczu u pacjentów po chordektomii
laserowej, która ma poprawiać czynność fonacyjną krtani. Materiałem do niniejszej pracy były badania dwóch pacjentów
po wykonanej chordektomii typu III z powodu raka fałdu głosowego w zaawansowaniu T1aN0M0. Pacjentom w siódmym i ósmym miesiącu po wykonaniu chordektomii wstrzyknięto tłuszcz do pozostałej części fałdu głosowego. Przed
laryngoplastyką i po niej u pacjentów przeprowadzono badanie foniatryczne oraz subiektywną i obiektywną ocenę głosu.
W wyniku laryngoplastyki iniekcyjnej u pacjentów uzyskano poprawę zwarcia fonacyjnego, jakości fonacyjnej głosu
oraz percepcyjną poprawę głosu. Laryngoplastyka iniekcyjna z wykorzystaniem autogennego tłuszczu u pacjentów po
chordektomii laserowej jest godna polecenia, szczególnie po chordektomii typu III.
SŁOWA KLUCZOWE: rak fałdu głosowego, chordektomia, augmentacja tłuszczem autogennym
34
DOI: 10.5604/20845308.1154499
WWW.OTORHINOLARYNGOLOGYPL.COM
doniesienie wstępne / preliminary report
INTRODUCTION
MATERIAL AND METHODS
Transoral endoscopic laser surgery has found widespread
use in the treatment of selected cases of early-stage glottic
carcinoma (T1N0M0 and T2N0M0) and became an alternative for radiation therapy and external access laryngofissure
surgery [1,2] . In 2000, the European Laryngological Society
(ELS) identified five types of laser cordectomy procedures.
The list was updated by addition of the sixth type in 2007
[3,4]. This classification has contributed to unification of
surgical nomenclature, thus facilitating comparison of treatment outcomes obtained in different centers. Surgical
interventions within the glottis lead to phonatory dysfunction. The quality of voice depends on the extent of surgery,
especially when resection involves the anterior commissure,
vocal process, arytenoid or contralateral vocal folds. Surgeries may lead to scarifications (pseudoglottis) that not only
differ in their appearance, but also restrict the glottic closure
and mobility, leading to potential disturbances in laryngeal
aerodynamics. Today, compromise is sought between oncological radicality of surgery and the voice quality outcomes.
Type I cordectomy, consisting only in the resection of the
epithelium, and type II cordectomy, consisting in the resection of the epithelium, Reinke’s space and vocal ligament, are
associated with minimum phonation disorders. Phonation
disorders are somewhat more pronounced in type II cordectomies involving the resection of vocal fold up to one half of
the width of the vocalis muscle [5,6]. Cordectomies of type
IV, V and VI are associated with markedly more significant
disturbances in voice quality [7] . Patients complain of hoarseness, vocal fatigue, dry throat, cough, feeling of foreign
body within the throat, and sometimes of difficulties with
swallowing. Thanks to the plasticity of the vocal system,
cordectomies with limited surgical range usually allow for
restoration of normal or nearly normal aerodynamic parameters and glottal closure [8] . Wider-range cordectomies
require multidisciplinary management consisting in vocal
therapy, pharmacotherapy and surgical (phonosurgical)
treatment [9]. Pharmacotherapy often includes steroid,
antibiotic, and anti-reflux therapies. Surgical treatment is
indicated in cases of scarifications leading to glottal insufficiency as well as in cases of aspiration-related symptoms.
The objective of surgery includes the achievement of optimum glottal closure and restoration of mucosal wave. Numerous surgical procedures are performed to improve the
phonatory function; one of them consists in autologous fat
injection [10,11,12,13,14,15,16]. The objective of this study is to evaluate the possibilities of injection laryngoplasty
using autologous fat in patients after laser cordectomy to
improve the phonatory function of the larynx .
The study material consisted of 2 patients, 7 and 8 months after
type III cordectomy due to stage T1aN0M0 vocal fold carcinoma (left-sided cordectomy was performed in both patients).
After surgery, typical pharmacotherapy, physical therapy, and
phoniatric rehabilitation were initiated in both patients with
the objective to achieve the best possible voice quality. As no
satisfactory results were obtained using these measures, decisions were made to subject the patients to surgical augmentation. Before augmentation, one patient reported significant
voice weakness and easy fatigability while the other one reported mainly increased vocal fatigability. Videostroboscopic examination of the first patient revealed normal mobility of both
vocal cords, boat-shaped glottal incompetence upon phonation,
with no features of cancer recurrence. No stroboscopic effect
was obtained due to the excess content of air in the generated
voice, preventing determination of fundamental frequency
(F0). The area of glottal incompetence during phonation was
measured by endoscopic assessment using DiagNova software to obtain the resultant value of 20.9 mm2 (Fig. 1). Acoustic
assessment carried out using MDVP software led to the following values: F0 = 113 Hz, Jitter = 10.1%, Shimmer = 12.96%,
NHR = 0,4. Maximum phonation time of vowel [a] (MPTa) was
4.9 s. The voice was perceptually assessed by 2 phoniatrists as
moderately changed, slightly coarse, with moderate-breathiness and asthenia, produced with medium strain (G2 R1 B2
A2 S2). VHI score was 45. In the other patient, preoperative
videostroboscopic assessment revealed normal mobility of
vocal folds, mucosal wave on the right vocal fold and no mucosal wave on the left vocal fold. Glottal closure during phonation was incomplete, boat-shaped, with incompetence area
of 4.2 mm2 (Fig. 2). Acoustic assessment by MDVP revealed
a fourfold increase in Jitter value (4.23%), twofold increase in
Shimmer value (6.82%) and the NHR value at the upper limit
of normal (0.14). Aerodynamic assessment revealed MPTa of
6 s. In the perceptual assessment, the voice was graded as G2
R1 B2 A2 S1. The patient assessed that his voice quality moderately reduced his quality of life (VRQoL score of 34 points).
POLSKI PRZEGLĄD OTORYNOLARYNGOLOGICZNY, TOM 4, NR 2 (2015), s. 34-39
The procedures were performed under general anesthesia.
Adipose tissue for autologous injection was collected from the
lower abdomen. After appropriate preparation, fat was injected by means of a special device and needle (Karl Storz GmbH
& Co. KG, Tuttlingen, Germany) bent at an appropriate angle
so as not to restrict the surgical field, featuring an injection
depth delimiter at the tip of the needle (Fig. 3). The injection
was delivered in direct laryngoscopy under microscopic control. Adipose tissue was injected into the remains of the vocal
folds laterally and deep from the vocal process and at ½ of the
35
doniesienie wstępne / preliminary report
Figure 1. Endoscopic assessment of the pharynx including the measurement of
the area of glottal incompetence during phonation (20.9 mm2) in a patient after
left-sided cordectomy due to pharyngeal cancer (Patient 1).
Figure 4. Endoscopic assessment of the pharynx including the measurement
of glottal incompetence during phonation in Patient 1 on Day 1 after
augmentation.
length of pseudoglottis. The injected volume was appropriate
to produce hypercorrection, i.e. slight bulging of pseudoglottis.
On the day after the augmentation, videostroboscopic evaluation of the first patient revealed a significant improvement of
the phonation closure as well as slight limitation of the mobility of the left vocal fold. The area of the incompetence at the
rima glottidis level was 3.4 mm2 (Fig. 4). Acoustic assessment
by means of MDVP revealed an improvement in the values of
Jitter (2.98%), Shimmer (4.76%) and NHR (0.13). MPTa was
elongated to 7.8 s. In the perceptual assessment, the voice was
graded as G1 R1 B1 A1 S0.
Figure 2. Endoscopic assessment of the pharynx including the measurement of
glottal incompetence during phonation in a patient after left-sided cordectomy
due to pharyngeal cancer (Patient 2). The area of glottal incompetence is 4.2
mm2.
Figure 3. A device and a needle (Karl Storz GmbH & Co. KG, Tuttlingen,
Germany), bent at an appropriate angle so as not to restrict the surgical field,
featuring an injection depth delimiter.
36
Next outpatient follow-up assessment carried out 3 months
after augmentation revealed the positive effects of augmentation being sustained despite the ongoing absorption of autologous fat. Videostroboscopic assessment revealed normal
mobility of both vocal folds with mucosal wave being observed
along the entire length of the right vocal fold The area of glottal
incompetence during phonation was still smaller than before
augmentation and amounted to 12.8 mm2. Jitter (5.27%) and
Shimmer (11.4 %) reflected a voice quality that was still better
than before the procedure. Maximum time of phonation of the
vowel [a] was shortened to 3.2 s. In the perceptual assessment,
the voice was graded as G2 R1 B2 A1 S1.
Phoniatric assessment of the patient 6 months after augmentation revealed phonation incompetence of rima glottidis of
8.3 mm2 (Fig. 5). The value was better than the one measured
in the previous assessment. This improvement as compared to
previous assessment was due to the increased hyperfunction
WWW.OTORHINOLARYNGOLOGYPL.COM
doniesienie wstępne / preliminary report
revealed improved glottal closure upon phonation (incompetence area of 3 mm2). Slight incompetence was observed only
in the posterior commissure. Moderate improvement in Jitter
value (3.69%) was observed compared to pre-augmentation
values. MPTa was elongated to 7.3 s. In the perceptual assessment, the voice improved in all subscales of the GRBAS scale (G1 R0 B1 A1 S0). Patient’s assessment of the quality of his
voice as well as voice-related quality of life were significantly
improved (VRQoL score of 15).
Figure 5. The measurement of glottal incompetence area in Patient 1 six months
after augmentation. On the left, rima glottidis is delimited by the protruding
left vestibular fold.
During the next follow-up assessment (3 months after augmentation), the patient was still satisfied with the results of
the phonosurgery procedure. Similar as in the case of the previous videostroboscopic assessment, slight incompetence was
observed upon phonation in the posterior part of the glottis
(1.5 mm2) (Fig. 6). Acoustic assessment revealed sustained improvement in Jitter (1.55%) and Shimmer parameters (5.074%)
as compared to pre-augmentation values. Maximum phonation time of vowel [a] (MPTa) was maintained at 7.4 s. The result of perceptual assessment was close to the result obtained
2 months earlier (G1 R0 B1 A1 S1). The development of slight
vocal strain might be due to better compensation of incompetence (lower phonation incompetence area) at the glottal level
as compared to the previous assessment. VRQoL score was at
the normal level of 11 points.
DISCUSSION
of the left vestibular fold participating in the glottal closure
during phonation. Probably, the involvement of the vestibular
fold in phonation had a negative effect on the voice quality as
reflected by increased values of Jitter (up to 9.82 %) and Shimmer (up to 19.25 %) and the perceptual grading of G2 R2 B2 A1
S1. VHI increased to the value of 60 which may be explained
by raised patient’s awareness of the changes and the quality of
voice as compared to before augmentation.
The material used for injection laryngoplasty as well as the
procedure itself should meet certain predefined criteria: the
material should be easily available, inexpensive and biocompatible while the surgical procedure should be simple and minimally invasive [11]. These requirements are met by autologous
fat that has been widely used in various surgeries within the
head and neck region [17]. Autologous fat is also widely used
in laryngoplasty for: 1. unilateral laryngeal paresis or paralysis; 2. developmental defects of vocal folds (sulcus vocalis and
congenital epithelial adhesion to the vocal ligament with failure to develop the Reinke’s space and absent mucosal wave;
3. the treatment of scars caused by previous surgeries (benign
or malignant changes of vocal folds; 4. the atrophy of vocal fold
following radiation therapy; 5. after previous failure of implant-injection laryngoplasty (inflammatory reaction of laryngeal
tissues involving tissue fibrosis)[13,14,15,16,17]. The interest
in the use of fat as injectable material is increasing as fat tissues
were found to posses characteristics typical of mesenchymal
stem cells (MSC), i.e. regeneration and differentiation [18].
In the second patient, phoniatric reassessment was performed
one month after augmentation. Videostroboscopic evaluation
The first injection laryngoplasty using paraffin administered
in direct laryngoscopy was reported by Brünning in 1911 [19].
Figure 6. The measurement of glottal incompetence area (1.5 mm2) in Patient
2 three months after augmentation. Slight incompetence within the posterior
rima glottidis region.
POLSKI PRZEGLĄD OTORYNOLARYNGOLOGICZNY, TOM 4, NR 2 (2015), s. 34-39
37
doniesienie wstępne / preliminary report
Autologous fat was used for the first time in injection laryngoplasty in vocal fold paresis by Mikaelian et al. [20] in 1991.
In 2001, it was used by Zeitels et al. [21] after cordectomy due
to vocal fold carcinoma.
Guven et al. [13] believe that the best period for fat injection is the first year after the cordectomy procedure. In this
period, appropriate rehabilitation and stabilization of pseudoglottis may significantly improve the phonation function
of the larynx. This period is also required for oncological
follow-up as most recurrences are observed within one year
after surgery. Villaret et al. [14] inject fat immediately after
cordectomy as a part of the same procedure. They believe
that injection of fat in the remaining part of the muscle following type III cordectomy is much easier than in the latter
period, when the scars hamper the injection; in addition,
patients do not require an additional surgical procedure.
Different opinions are held by different authors with regard to the injection site; some authors suggest a single injection in the remains of the vocalis muscle, others suggest
two injections, one lateral and deep from the vocal process
and the other anteriorly right under the remaining mucosa
covering a part of the vocal fold, while yet another authors
inject the fat into the periglottal space. The injected fat volume should be appropriate to produce hypercorrection, i.e.
slight bulging of pseudoglottis. According to many authors,
injection laryngoplasty using autologous fat in patients after
laser cordectomy is highly recommended as it results in improved phonation closure and phonatory voice quality as
well as perceptual improvement of the voice, particularly
following cordectomies characterized by a small-range of
tissue resection. In cordectomies with a larger range of tissue
resection, the technique may be combined with simultaneous use of other phonosurgical techniques [5,11,13,14,15].
References
1.
Lachowska M., Osuch-Wójcikiewicz E., Bruzgielewicz A.: Clinical research videolaryngoscopic and videostroboscopic evaluation following laser CO2 and
conventional cordectomy of Tis and T1 glottic carcinoma. Arch. Med. Sci., 2010;6 (4): 623-632.
2.
Lachowska M., Osuch-Wójcikiewicz E., Bruzgielewicz A.: Clinical research voice evaluation following endoscopic laser CO2 cordectomy and conventional
cordectomy. Arch. Med. Sci., 2011;7(1):143-153.
3.
Remacle M., Eckel H.E., Antonelli A., Brasnu D., Chevalier D., Friedrich G., Olofsson J., Rudert H.H., Thumfart W., de Vincentiis M., Wustrow TP.: Endoscopic
cordectomy. A proposal for a classification by the Working Committee, European Laryngological Society. Eur. Arch. Otorhinolaryngol., 2000;257(4):227-231.
4.
Remacle M., Van Haverbeke C., Eckel H., Bradley P., Chevalier D., Djukic V., de Vicentiis M., Friedrich G., Olofsson J., Peretti G., Quer M., Werner J.: Proposal for revision of the European Laryngological Society classification of endoscopic cordectomies. Eur. Arch. Otorhinolaryngol., 2007;264(5):499-504.
5.
Peretti G., Piazza C., Balzanelli C., Mensi M.C., Rossini M., Antonelli A.R.: Preoperative and postoperative voice in Tis-T1 glottic cancer treated by endoscopic cordectomies: an additional issue for patient counseling. Ann. Otol. Rhinol. Laryngol., 2003;112:759-763.
6.
Schindler A., Palonta F., Preti G., Ottaviani F., Schindler O., Cavalot A.L.: Voice quality after carbon dioxide laser and conventional surgery for T1A glottic
carcinoma. J. Voice, 2004 ;18(4):545-550.
7.
Galletti B., Freni F., Cammaroto G., Catalano N., Gangemi G., Galletti F.: Vocal outcome after CO2 laser cordectomy performed on patients affected by early
glottis carcinoma. J. Voice, 2012; 26 (6) : 801-805.
8.
Wallet L.: An aerodynamic study of labial stop consonants after laser cordectomy of types II-III. J. Voice. http://dx.doi.org/10.1016/j.jvoice.(2014.07.011).
9.
Sıttel C., Friedrich G., Zorowka P., Eckel H.E.: Surgical voice rehabilitation after laser surgery for glottic carcinoma. Ann. Otol. Rhinol. Laryngol., 2002; 111:
493-499.
10. Remacle M., Lawson G., Morsomme D., Jamart J.: Reconstruction of glottic defects after endoscopic cordectomy: voice outcome. Otolaryngol. Clin. N. Am.,
2006;39:191-204.
11. Cavanagh J. P., Hart R.D., Brown T., Trites J.R.B., Brake M., Taylor S.M.: Laryngeal reconstruction following CO2 laser surgery for glottis cancer. Head Neck,
2009;31(10):1369-1376.
12. Friedrich G., Dikkers F.G., Arens C., Remacle M., Hess M., Giovanni A., Duflo S., Hantzakos A., Bachy V., Gugatschka M.: Vocal fold scars: current concepts
and future directions. Consensus report of the phonosurgery committee of the European laryngological society. Eur. Arch. Otorhinolaryngol., DOI 10.1007/
s00405-013-2498-9.
13. Guven M., Suoglu Y., Kıyak E., Demir D.: Autologous fat augmentation for voice and swallow improvement after cordectomy. ORL, 2006;68:164-169.
14. Villaret A.B., Piazza C., Redaelli De Zinis L.O., Cattaneo A., Cocco D., Peretti G.: Phonosurgery after endoscopic cordectomies I. Primary intracordal autologous fat injection after transmuscular resection: preliminary results. Eur. Arch. Otorhinolaryngol., 2007;264:1179-1184.
15. Piazza C., Villaret A.B., Redaelli De Zinis L.O., Cattaneo A., Cocco D., Peretti G.: Phonosurgery after endoscopic cordectomies II. Delayed medialization
techniques for major glottic incompetence after total and extended resections. Eur. Arch. Otorhinolaryngol., 2007;264:1185-1190.
16. Domeracka-Kołodziej A., Niemczyk K., Bruzgielewicz A., Sielska-Badurek E.: Wczesne wyniki czynnościowe po laryngoplastyce injekcyjnej z wykorzystaniem autogennego tłuszczu u pacjentów z jednostronnym porażeniem krtani. Otorynolaryngologia, 2010; 9(4): 176-183.
38
WWW.OTORHINOLARYNGOLOGYPL.COM
doniesienie wstępne / preliminary report
17. Mazzola R.F., Cantarella G., Torretta S., Sbarbati A., Lazzari L., Pignataro L.: Autologous fat injection to face and neck: from soft tissue augmentation to regenerative medicine. Acta. Otorhinolaryngol. Ital., 2011;31:59-69.
18. Zuk P.A., Zhu M., Ashjian P., De Ugarte D.A., Huang J.I., Mizuno H., Alfonso Z.C., Fraser J.K., Benhaim P., Hedrick M.H.: Human adipose tissue is a source
of multipotent stem cells. Mol. Biol. Cell., 2002;13:4279-4295.
19. Brünnings W.: Eine neue behandlungsmethode der rekurrenslahmungen.
20. Verhandl. Deutsch. Vereins. Deutscher. Laryngol., 1911;18:93-151.
21. Mikaelian D.O., Lowry L.D., Sataloff R.T.: Lipo-injection for unilateral vocal cord paralysis. Laryngoscope, 1991;101:465-468.
22. Zeitels S.M., Jarboe J., Franco R.A.: Phonosurgical reconstruction of early glottic cancer. Laryngoscope, 2001;111:1862-1865.
Word count: 1716 Tables: – Figures: 6 References: 22
Access the article online: DOI: 10.5604/20845308.1154499 Full-text PDF: www.otorhinolaryngologypl.com/fulltxt.php?ICID=1154499
Corresponding author: Antoni Bruzgielewicz, Katedra i Klinika Otolaryngologii Warszawskiego Uniwersytetu Medycznego, e-mail: antek@
amwaw.edu.pl
Copyright © 2015 Polish Society of Otorhinolaryngologists Head and Neck Surgeons. Published by Index Copernicus Sp. z o.o. All rights reserved Competing interests: The authors declare that they have no competing interests.
Funding: Praca w ramach realizacji projektu rozwojowego nr 13-0101-10 finansowanego z funduszy NCBiR.
Cite this article as: Bruzgielewicz A., Sielska-Badurek E., Niemczyk K., Osuch-Wójcikiewicz E.: Injection laryngoplasty with autologous fat in patients after laser cordectomy
– preliminary report.. Pol Otorhino Rev 2015; 4(2): 34-39
POLSKI PRZEGLĄD OTORYNOLARYNGOLOGICZNY, TOM 4, NR 2 (2015), s. 34-39
39
